Technical data
- Power consumption: 1200W
- Power supply voltage: 100 – 245V
- Voltage frequency: 50/60Hz
- Diode type: COB 6in1
- Diode power: 300W
- Display: Color LCD
- Number of diodes: 4
Utility data
- Color: RGBWA + UV
- Luminous flux: 105 040lm
- Beam angle (min): 37°
- Beam angle (max): 37°
- Dimming:Linear: 0 – 100%
- Number of DMX channels: 21 (6-32CH)
- DMX standard: DMX 512
- Control interface: 4 buttons
- Operating modes: DMX512, Auto, Sound-controlled, Master / Slave
- Features: 16-bit dimming, various dimming curves, bulb simulation, DMX Signal regeneration,
- Electronic protection against overheating
Interfaces
- AC IN: powerCON
- DMX IN: XLR – 3 pin
- DMX OUT: XLR – 3 pin
Physical characteristics
- Housing made: ABS
- Cooling: Active, temperature-controlled
- Height [cm]: 19
- Width [cm]: 62
- Depth [cm]: 27
- Weight [kg]: 9,4
- Type of packaging: Carton Box
